Fly Ash Automatic Brick Making Machine (Techno 12)

Our Techno 12 Fly Ash Brick Machine is a medium range production unit. This machine offers 16,000 to 18,000 bricks/8 hours. We provide conveyor for production process and bricks collection. We help you in terms of generating ROI for your business with our experts customized plan.

Specification

SPECIFICATIONS TECHNO 12
Power Hydraulic Motor 15 Hp
Brick Eject Conveyor Motor 2 Hp
Production 12 Bricks / Per Stroke (9"X4 1/4"X3")
Cycle Time 15-20 Seconds
Pre Fill Hydraulic System For Quick Operation
Hopper Capacity 500 Kg
Operating Pressure 140-200 Bar
Capacity 16000 – 18000 Bricks/8 Hours (Shift)
Hydraulic Oil System Capacity 420 Litres
Conveyor Used For Production Process & Bricks Collection.
Pressure Control Automatic
Body Single Plate Fabrication
Brick Mould Changeable System Frog On The Bricks
Feature Anti - Brick Crack Mould System
Control Panel PLC Systems
